SQ2348ES-T1_GE3

Category : Discrete Semiconductor Products Transistors FETs, MOSFETs Single FETs, MOSFETs

FET Feature : -

Vgs(th) (Max) @ Id : 2.5V @ 250µA

Operating Temperature : -55°C ~ 175°C (TJ)

Package / Case : TO-236-3, SC-59, SOT-23-3

Gate Charge (Qg) (Max) @ Vgs : 14.5 nC @ 10 V

Rds On (Max) @ Id, Vgs : 24mOhm @ 12A, 10V

FET Type : N-Channel

Drive Voltage (Max Rds On, Min Rds On) : 4.5V, 10V

Package : Tape & Reel (TR) Cut Tape (CT) Digi-Reel®

Drain to Source Voltage (Vdss) : 30 V

Vgs (Max) : ±20V

Product Status : Last Time Buy

Input Capacitance (Ciss) (Max) @ Vds : 540 pF @ 15 V

Mounting Type : Surface Mount

Series : TrenchFET®

Supplier Device Package : SOT-23-3 (TO-236)

Mfr : Vishay Siliconix

Current - Continuous Drain (Id) @ 25°C : 8A (Tc)

Power Dissipation (Max) : 3W (Tc)

Technology : MOSFET (Metal Oxide)

Base Product Number : SQ2348

Description : MOSFET N-CH 30V 8A TO236
